MODEL | 4' Rear | 5' Rear | 6' Rear |
# ASSEMBLY | 52-034 | 52-035 | 52-036 |
VEHICULE | |||
Recommended vehicule | 30 HP | 45 HP | 60 HP |
Minimum tractor weight | 2500 lbs | 3000 lbs | 4000 lbs |
DIMENSIONS | |||
Cutter width dimensions | 48" | 60" | 72" |
Blade rotation +/- | 910 rpm | 910 rpm | 910 rpm |
P.T.O. | 540 | 540 | 540 |
P.T.O. Clutch | Standard | Standard | Standard |
P.T.O. Category | 40 | 50 | 50 |
Gearbox (Capacity) | 40 HP | 60 HP | 60 HP |
Anti projection Frontward / Backward protection (3/8 Chain) | Standard | Standard | Standard |
Optional real wheel | Standard | Standard | Standard |
WEIGHT | |||
Weight of the brushcutters | 490 lbs | 810 lbs | 960 lbs |
