Ideal for 65 - 100 HP Tractors
712 V Series Dump trailer
Assembly part no.: 59-114
DUMP TRAILER | |
DIMENSIONS | |
Trailer | 84" x 144" |
Side pannel | 22" |
Floor height | 48" |
Lateral wall height | 70" |
Front and back pannel (removable) | 40" |
TECHNICAL SPECIFICATION | |
Load | 15 tonnes |
Axle | 8 bolts |
Axle capacity | 10000 lbs |
Cylinder | 1 x 12 tonnes |
manual trailer hitch | 8000 lbs |
VOLUME | |
Without (extra side pannel ) | 150 cubic feets |
with (extra side pannel) | 281 cubic feets |
INFORMATIONS | |
Back pannel openning | automatic |
Grain doors | optionnel |
Axle | Tandem |
Clevis coupling | standard |
Standard Tires | 425/65-22.5, 20 ply |
550/45-22.5, 16 ply | |
WEIGHT | |
Approx Weight | 6200 lbs |
